Battery Packs Li-Ion, Li-Poly and NiMH

배터리 팩은 국제적으로 인정된 브랜드의 전지로 조립되며 고객의 요구사항 및 응용 요구사항을 기반으로 덜 알려진 중국 제조업체에서 저렴한 비용으로 조립할 수 있습니다. 인기 브랜드는 다음과 같습니다:

우리는 모든 고객이 지정한 배터리를 소싱 또는 구입할 수 있으며 요구사항에 따라 선택하는 것을 도울 수 있습니다.

  • 휴대용 의료 기기
  • 휴대용 전자 기기
  • 안전 및 보안
  • 군사 및 항공 우주
  • 전동 공구 및 기기
  • 통신
  • 가전
  • 데이터 수집
  • 전기 자동차
  • 충전식 가정용 및 상용 제품
  • 테스트 및 측정 장치
  • UPS 시스템
  • 사용자 맞춤형 배터리 팩 설계
  • 배터리 관리 회로 설계
  • 성능 검증
  • 사용자 맞춤형 충전기 개발
  • 배터리 팩 조립
  • 인쇄회로기판(PCB) 조립
  • 의료 설계 및 플라스틱/금속 부품 또는 외함 제작
  • 생산 테스트
  • 환경 제어 저장소
  • 규정 승인
  • UN38.3 테스트와 같은 교통 시험

GlobTek US Headquarters and Manufacturing Facility in Northvale, NJ
https://goo.gl/maps/Yo6k6
American flag GlobTek, Inc. USA
Headquarters

186 Veterans Drive
Northvale, NJ 07647
USA

Tel: +1-201-784-1000
Fax: +1.201.784.0111
33,000 sq. ft.
65 Employees


GlobTek China Headquarters and Manufacturing Facility in Suzhou, China
http://j.map.baidu.com/LODCw
Chinese flag GlobTek (Suzhou) Co. Ltd.
Asia Pacific Regional Factory

Building 4, City Illumination
Industrial Park,
76 East Jinling Road,
Weting Town,
Suzhou Industrial Park,
Suzhou, 215021
China

Tel: +86-512-6279-0301
Fax: +86-512-6279-0355
100,000m2
500 Employees

설계, 통합 및 사용자 정의 배터리 팩과 배터리 충전기 제조의 선두 주자로서, GlobTek은 휴대용 전자 제품들이 더 믿음성 있고, 더 작고, 더 가볍고 그리고 더 오랜 기간 실행할 수 있도록 합니다. GlobTek의 설계 엔지니어 팀은 더 빠르고, 더 효과적인 시스템의 제작을 위해 고객의 요구 사항을 기반으로 완벽한 전력 솔루션을 개발하고 있습니다.

배터리 팩: 사용자 정의 설계 및 조립

전원 품질은 지난 10 년 사이에 많은 논의 주제로 떠오르고 있으며 더 많은 애플리케이션이 마이크로 프로세서를 기반으로 하고 있으므로 이것은 중요한 요인으로 남아있게 될 것으로 예상됩니다. 전자에 대한 의존도가 증가되면서, 전력 품질에 대한 욕구와 요구는 멈춰서지 않을 것입니다.

고객은 간단히 밀봉된 연축전지로 부터 전자적인 안전, 모니터링 및 충전 제어 회로를 포함하는 복잡한 리튬 이온 팩에 이르기까지의 안전하고 신뢰할 수있는 사용자 정의 배터리 팩 설계를 GlobTek에 의존하고 있습니다. 전원 공급 장치 제품, 플라스틱 하우징, 인터커넥트 , 및 전자 회로분야의 우리의 광범위한 경험은 우리에게 최첨단의 휴대용 전원 소스를 구축하는 데 필요한 많은 핵심 프로세스를 아웃소싱하는 배터리 제작자들에 비해 엄청난 경쟁 우위를 제공합니다.

각각의 특정 응용을위해 설계된 사용자 정의 배터리 충전기에 우리의 맞춤형 배터리 팩을 일치시키는 GlobTek의 능력은 우리가 경쟁사에 비해 한단계 앞서 나가게하며 고객을 유지하게 합니다. 우리는 최상의 성능을 제공하기 위해 설계 단계에서 배터리 팩 및 배터리 충전기를 모두 설계하고 최적화합니다.

UL1642 Listing card 자세한 정보 요청 Guidelines and cautions


GlobTek Quality Control Engineering

배터리 전지 유형


배터리 공식 성능


전지 유형 직류 볼트 충전 와트/리터 가격 비율 문제
NiMH 1.2 500 to 1,000 300 100% 없음
NiCd 1.2 300 to 500 134 80% 메모리, 폐기
Li-Ion 3.6 300 to 400 287 200% 안전/화재, 폐기

IEC62133 certified batteries

Model numberCell ChemistryBattery Pack Voltage VBattery Pack Capacity mAhBattery Pack Dimensions MMHas NTC ThermistorHas Fuel GaugeHas Built-in Charger CircuitryConfigurationCell typeCell shapeCell Dimensions MMConnector
BL0105F2635161S1PCATLithium Polymer3.71052.8*16.5*37NoNoNo1S 1PGP261635Rectangular2.80x16.50x37.00Per Customer Spec
BL0750F5030481S1PCMC Lithium Polymer3.770050.5x30.5x5.310KNoNo1S 1PGP503048 Rectangular 50.5x30.5x5.3 Per Customer Spec
BL0700C1450141S1PCACLi-Ion Polymer3.770053 x 14mmNoNoNo1S1PUR14500PCylindrical 53 x 14mmPer Customer Spec
BL1200P4054481S1PCACLithium Polymer3.7120053.0x48.0x410KNoNo1S 1PGP404852Rectangular4.0x48x53Per Customer Spec
BL2200F6034501S2xxxxLithium Ion3.7220051x34x13NoNoNo1S 2P603450Rectangular6.4x34x50Per Customer Spec
Call or email for Stock Modified and Customized solutions available with no or low minimum quantities
BL3000F9031781S1PCRVLithium Ion Polymer3.7300078 x 31 x 9.0mm10KNoNo1S1P903178Rectangular 78 x 31 x 9.0mmSamtec SISS-05-28C-GF-03.00-L
BL2600C1865001S2PxxxxLithium Ion3.7480019x68.5x37NoNoNo1S 2PICR18650-26FCylindrical18x65x00Per Customer Spec
BL1880F6835661S5PX9MLithium Polymer3.79400185.5*69.5*7.9 mm10KBQ27200No1S5PGP683566Rectangular6.8*35*66Molex 9P Header: 53015-0910
BL1800P0639602S1PPLBLithium Polymer7.4180061.5X42.0X14.010KNoNo2S 1PLithium PolymerRectangular61.5X42.0X14.0JST XHP-4PIN
BL2600C1865003S1PGQGLithium-Ion11.1260055.5x66.0x23.0NoYesYes3S1PNCR18650A-26FCylindrical18x65x00Molex 6P header: 43025-0600
Call or email for Stock Modified and Customized solutions available with no or low minimum quantities
BL2600C1865004S1PxxLithium Ion14.8260077x69NoYesNo4S 1PICR18650-26FCylindrical18x65x00Per Customer Spec
BL2600C1865004S1PG1Lithium Ion14.8260066*73.5*28.5NoYesYes4S 1PICR18650-26FCylindrical18x65x00Per Customer Spec

Standard battery packs

  • GlobTek announces the release of BS1200C1425001S1PCMW, an industry standard package size for water metering applications. The battery pack features a 3.6V operating voltage and 1200mAh current capacity. Lithium-thionyl chloride (Li-SoCl2) battery pack features 3.6V Operating voltage and 1200mAh capacity in a small 1/2AA form factor with Molex(2695) 22-01-3027 (2 pin) Termination, BS1200C1425001S1PCMW
  • BL1880F6835661S5PG9x is an addition to the growing family of GlobTek’s IEC 62133 Certified High-Capacity Battery Packs with the host of Safety, Monitoring and Connecting features.

Beginning May 1st,... IEC62133 Certified Lithium Polymer (Li-Po) 3.7V, 9400mAh Battery Pack Features High Capacity and Integrated Connector!
  • GlobTek’s Battery Packs Feature Multi-Chemistry Designs and Latest IATA 56th Edition Compliance!

Power quality has emerged as a much discussed topic within the last ten years and is anticipated to remain... GlobTek’s Lithium Polymer (Li-Po), Nickel Cadmium (Ni-Cad) and Lithium Ion (Li-Ion) Battery Packs are Updated to IATA Dangerous Goods Regulations 56th Edition!
  • GlobTek’s Wearable Curved 3.7 @ 28mAh Li-Po Battery Pack Designed to Meet UL 1642 Cell Approval!
A leader in the design, integration, and manufacture of custom battery packs and battery chargers, GlobTek... Wearable Conformal Flexible Lithium Polymer (Li-Po) Battery Packs from GlobTek are Now Available in Unlimited Sizes and Shapes, Plus Either Meet or are Designed to Meet UL 2054, UL 1642 Cell Certification, IEC-62133 and a CE Mark which complies with 2004/108/EC Electromagnetic compatibility, including EN61000-6-1:2007, EN61000-6-3:2007!
  • GlobTek’s BL2600C1865001S2PRML Battery Pack in 1S2P Configuration represents latest addition to rugged high-capacity Li-Ion / Cylindrical Battery family with UL 1642 Approved Cells and a CE Mark which... Li-Ion Cylindrical Battery Pack from GlobTek, a 3.7 VOLTS @ 5200mAh BL2600C1865001S2PRML Now Features UL 1642 Cell Approval and a CE Mark which complies with 2004/108/EC Electromagnetic compatibility, including EN61000-6-1:2007, EN61000-6-3:2007!
  • GlobTek’s BL0105F2635161S1PCAT Battery Pack represents latest addition to miniature iPod nano - compatible high-capacity Li-Ion / LiPo (Polymer) Battery family with UL 2054 Approved Pack and a IEC/EN... Miniature Li-Ion Polymer Battery Pack BL0105F2635161S1PCAT, 3.7V @ 105mAh Now Features UL 1642 Cell Approval and UL2054 Pack Approval (pending), as well as IEC/EN 62133 1st & 2nd Edition Certification!
  • GlobTek’s BL1800P0639602S1PPLB Battery Pack represents latest addition to rugged high-capacity Li-Ion / Prismatic Battery family with UL 1642 Approved Cells and a CE Mark which complies with 2004/108/EC... Li-Ion Prismatic Battery Pack BL1800P0639602S1PPLB, 7.4V @ 1800mAh Now Features UL 1642 Cell Approval and a CE Mark which complies with 2004/108/EC Electromagnetic compatibility, including EN61000-6-1:2007, EN61000-6-3:2007!!
  • GlobTek’s 2GL-523450-G2107(R) Battery Pack represents latest addition to a complete charging solution (Battery Pack, Charger, Multi-bay Charging Cradle), featuring UL 1624 approved high capacity polymer... Li-Ion Polymer Battery Pack 2GL-523450-G2107(R), 3.7V @ 2000mAh Now Features UL 1642 Cell Approval and is ROHS complient!
  • GlobTek’s BL1950P1034502S1PQPA Battery Pack in 2S1P Configuration represents latest addition to rugged high-capacity Li-Ion / Prismatic Battery family with UL 1642 Approved Cells and a CE Mark which... Li-Ion Prismatic Battery Pack from GlobTek, a 7.4V / 1950mAh BL1950P1034502S1PQPA Features UL 1642 Cell Approval and is designed to meet CE Mark which complies with 2004/108/EC Electromagnetic compatibility, including EN61000-6-1:2007, EN61000-6-3:2007!
  • GlobTek’s BL1400C1850001S2PRML Battery Pack in 1S2P Configuration represents latest addition to rugged high-capacity Li-Ion / Cylindrical Battery family with UL 1642 Approved Cells and a CE Mark which... BL1400C1850001S2PRML, Li-Ion Cylindrical Battery Pack from GlobTek, a 3.7 VOLTS @ 2800mAh now Features UL 1642 Cell Approval and a CE Mark which complies with 2004/108/EC Electromagnetic compatibility, including EN61000-6-1:2007, EN61000-6-3:2007!
  • GlobTek’s BL2200F6034501S2PPML Battery Pack in 1S2P Configuration represents latest addition to rugged high-capacity Li-Ion / Prismatic Battery family with UL 1642 Approved Cells and a CE Mark which... Li-Ion Prismatic Battery Pack from GlobTek, a 3.7 VOLTS @ 2200 mAh BL2200F6034501S2PPML Now Features UL 1642 Cell Approval and a CE Mark which complies with 2004/108/EC Electromagnetic compatibility, including EN61000-6-1:2007, EN61000-6-3:2007!
  • GlobTek’s BL2600C18654S1PG2646 Battery Pack represents latest addition to rugged high-capacity Li-Ion / Polymer Battery family with UL 1642 Approved Cells and a CB Certification to 62133:2012 (Second... GlobTek’s 14.8V @ 2,600mAh Li-Ion Battery Pack is Now CB Certified to 62133:2012 2nd Edition!
